| Nomor Bagian | M240HW01 V8 |
| Merek | AUO |
| Ukuran | 24.0 |
| Aplikasi | DMPC |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | AUO |
| model panel | M240HW01 V8 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 24.0 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 531.36×298.89 mm |
| garis besar | 556×323.2×14.9 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 350 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) |
| menampilkan warna | 16.7M (6-bit + Hi-FRC), CIE193172% |
| waktu merespon | 3.5/1.5 (Typ.)(Tr/Td) |
| sudut pandang | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 120Hz |
| jenis lampu | 14S4PWLEDWithout Driver |
| antarmuka sinyal | LVDS (4 ch, 8-bit), 66 pins |
| tegangan masukan | 5.0V (Typ.) |
| aplikasi | DMPC |
