| Nomor Bagian | M236HJJ-P02 Rev.C4 |
| Merek | Innolux |
| Ukuran | 23.6 |
| Aplikasi | Desktop Monitor |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 3000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | |
| merek | Innolux |
| model | M236HJJ-P02 Rev.C4 |
| ukuran diagonal | 23.6 inch |
| jenis | a-Si TFT-LCD, CELL |
| format piksel | 1920(RGB)×1080 [FHD] 93PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 521.28(H)×293.22(V) mm |
| garis besar redup. | 534.28(H)×306.252(V) mm |
| daerah bezel | - |
| perlakuan | Antiglare (Haze 25%), Hard coating (3H) |
| pencahayaan | 0 cd/m² |
| rasio kontras | 3000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 20/5 (Typ.)(Tr/Td) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| Modus operasi | Super MVA, Normally Black, Transmissive |
| ketebalan pelat | - |
| transmisi | 4.8% (Typ.)(with Polarizer) |
| warna pendukung | 16.7M 72% NTSC |
| sumber cahaya | No B/L |
| berat | TBD |
| dirancang untuk | Desktop Monitor |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| HM236WU3-100 | BOE | 23.6 | 1920×1080 |
| HR236WU1-300 | BOE | 23.6 | 1920×1080 |
| HV236WHB-N00 | BOE | 23.6 | 1366×768 |
| M236HJJ-L30 | Innolux | 23.6 | 1920×1080 |
| M236HJJ-P02 | Innolux | 23.6 | 1920×1080 |
| MV236FHB-N10 | BOE | 23.6 | 1920×1080 |
| MV236WHM-N10 | BOE | 23.6 | 1366×768 |
| V236BJ1-P01 Rev.C3 | Innolux | 23.6 | 1366×768 |
| V236BJ1-PE2 | Innolux | 23.6 | 1366×768 |
| V236H1-L01 | Innolux | 23.6 | 1920×1080 |
