V236BJ1-P01 Rev.C3

V236BJ1-P01 Rev.C3
V236BJ1-P01 Rev.C3 thumb
Merek
Innolux
Ukuran
23.6
Aplikasi
LCTV
Resolusi
1366×768
Komposisi
CELL
Kecerahan
0
CR
3000:1
Warna
16.7M
Lampu latar
No B/L
Antarmuka
LVDS
In Stock
6347
Spesifikasi

Nomor Bagian V236BJ1-P01 Rev.C3
MerekInnolux
Ukuran23.6
AplikasiLCTV
Resolusi1366×768
KomposisiCELL
Kecerahan0
CR3000:1
Warna16.7M
Lampu latarNo B/L
AntarmukaLVDS
merek panelCHIMEI INNOLUX
model panelV236BJ1-P01 Rev.C3
tipe panel a-Si TFT-LCD , CELL
ukuran panel23.6 inch
resolusi1366(RGB)×768 , WXGA
mode tampilanMVA, Normally Black, Transmissive
daerah aktif521.471×293.184 mm
garis besar535.06×307.34 mm
permukaanAntiglare (Haze 1%), Hard coating (3H)
kedalaman kaca0.50+0.50 mm
keterusan5.6% (Typ.)(with Polarizer)
rasio kontras3000:1 (Typ.)
menampilkan warna16.7M (8-bit), CIE193172%
waktu merespon8.5 (Typ.)(G to G)
sudut pandang88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
frekuensi60Hz
antarmuka sinyalLVDS (1 ch, 8-bit), 30 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
