| Nomor Bagian | M185XW01 V3 |
| Merek | AUO |
| Ukuran | 18.5 |
| Aplikasi | DMPC |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | AUO |
| model panel | M185XW01 V3 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 18.5 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 409.8×230.4 mm |
| garis besar | 430.4×254.6×12.3 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 250 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) |
| menampilkan warna | 16.7M (6-bit + Hi-FRC), CIE193167% |
| waktu merespon | 3.6/1.4 (Typ.)(Tr/Td) |
| sudut pandang | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antarmuka sinyal | LVDS (1 ch, 8-bit), 30 pins |
| tegangan masukan | 5.0V (Typ.) |
| aplikasi | DMPC |
