| Nomor Bagian | M090AWP4 R0 |
| Merek | IVO |
| Ukuran | 9.0 |
| Aplikasi | Outdoor High Brightn |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K |
| Lampu latar | 8S3P |
| Antarmuka | Parallel |
| merek panel | IVO |
| ukuran panel | 9.0" |
| resolusi | 800(RGB)×480, WVGA, 104PPI |
| area tampilan | 198(W)×112.08(H) mm |
| ukuran garis besar | 210.82(W)×126.96(H) ×6.4(D) mm |
| kecerahan | 750 cd/m² (Typ.) |
| sudut pandang | 70/70/50/70 (Typ.)(CR≥10) |
| tampilan terbaik di | 6 o'clock |
| menampilkan warna | 262K 70% NTSC |
| frekuensi | 60Hz |
| berat panel | 251g (Max.) |
| antarmuka sinyal | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| tegangan masukan | 3.3/11.6/22/-7V (Typ.)(VCC/VDDA/VGH/VGL) |
| lingkungan | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| model panel | M090AWP4 R0 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | 200.2(W)×114.28(H) mm |
| permukaan | Antiglare, Hard coating (3H) |
| rasio kontras | 700:1 (Typ.) (TM) |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 12 (Typ.)(Tr+Td) |
| jenis lampu | 8S3P WLED , 30K hours , Without Driver |
| layar sentuh | Without |
| aplikasi | Outdoor High Brightness Automotive Display |
