| Nomor Bagian | M080AWT8 R1 |
| Merek | IVO |
| Ukuran | 8.0 |
| Aplikasi | Automotive Display |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | IVO |
| model | M080AWT8 R1 |
| ukuran diagonal | 8.0 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×600 [WSVGA] 148PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 176.64(H)×99.36(V) mm |
| garis besar redup. | 192.8(H)×116.9(V) ×8.35(D) mm |
| daerah bezel | 178.84(H)×101.56(V) mm |
| perlakuan | Antiglare |
| pencahayaan | 670 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) (TM) |
| arah pandangan | 6 o'clock |
| waktu merespon | 16 (Typ.)(Tr+Td) |
| sudut pandang | 75/75/70/75 (Typ.)(CR≥10) |
| Modus operasi | TN, Normally White, Transmissive |
| warna pendukung | 262K/16.7M 72% NTSC |
| sumber cahaya | WLED [3S7P] , 30K hours , W/O Driver |
| berat | 240g (Max.) |
| dirancang untuk | Automotive Display |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | LVDS (1 ch, 6/8-bit) , 40 pins FPC |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C |
