| Nomor Bagian | TV080X0M-NS0 |
| Merek | BOE |
| Ukuran | 8.0 |
| Aplikasi | PAD |
| Resolusi | 768×1024 |
| Komposisi | LCM |
| Kecerahan | 450 |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek panel | BOE |
| model panel | TV080X0M-NS0 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 8.0 inch |
| resolusi | 768(RGB)×1024 , XGA |
| mode tampilan | ADS, Normally Black, Transmissive |
| daerah aktif | 121.882×162.509 mm |
| garis besar | 128.142×173.739 mm |
| permukaan | |
| kecerahan | 450 cd/m² (Typ.) |
| rasio kontras | 900:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193171% |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 8S3PWLEDWithout Driver |
| antarmuka sinyal | MIPI (4 data lanes), 34 pins |
| tegangan masukan | 1.8/5.4/-5.4V (Typ.)(Vio/Vsn/Vsp) |
| aplikasi | PAD |
