| Nomor Bagian | LTN170BT11-D01 |
| Merek | Samsung |
| Ukuran | 17.0 |
| Aplikasi | NBPC |
| Resolusi | 1440×900 |
| Komposisi | LCM |
| Kecerahan | |
| CR | |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | SAMSUNG |
| model panel | LTN170BT11-D01 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 17.0 inch |
| resolusi | 1440(RGB)×900 , WXGA+ |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 367.2×229.5 mm |
| gaya bentuk | Wedge (PCBA Bent, Depth ≥5.2mm) |
| permukaan | |
| kecerahan | |
| rasio kontras | |
| menampilkan warna | 262K (6-bit) |
| waktu merespon | |
| sudut pandang | |
| frekuensi | 60Hz |
| jenis lampu | WLED |
| antarmuka sinyal | LVDS (2 ch, 6-bit) |
| aplikasi | NBPC |
