| Nomor Bagian | LTM230HL10-C01 |
| Merek | SAMSUNG |
| Ukuran | 23.0 |
| Aplikasi | Desktop Monitor |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek panel | SAMSUNG |
| ukuran panel | 23.0" |
| resolusi | 1920(RGB)×1080, FHD, 95PPI |
| area tampilan | 509.184(W)×286.416(H) mm |
| ukuran garis besar | 522.38(W)×305.62(H) ×12.6(D) mm |
| kecerahan | 250 cd/m² (Typ.) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 72% NTSC |
| frekuensi | 60Hz |
| berat | 2.38Kgs (Max.) |
| model panel | LTM230HL10-C01 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | 512.384(W)×289.616(H) mm |
| permukaan | - |
| rasio kontras | 1000:1 (Typ.) (TM) |
| mode tampilan | PLS, Normally Black, Transmissive |
| waktu merespon | 14 (Typ.)(G to G) |
| jenis lampu | WLED , 40K hours , Without Driver |
| layar sentuh | Without |
| aplikasi | Desktop Monitor |
