| Nomor Bagian | LTA104S2-L01 |
| Merek | Samsung |
| Ukuran | 10.4 |
| Aplikasi | IA |
| Resolusi | 800×600 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 150:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | SAMSUNG |
| model panel | LTA104S2-L01 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 10.4 inch |
| resolusi | 800(RGB)×600 , SVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 211.2×158.4 mm |
| garis besar | 246×177.8 mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 350 cd/m² (Typ.) |
| rasio kontras | 150:1 (Min.) |
| menampilkan warna | 262K (6-bit) |
| waktu merespon | 10/30 (Typ.)(Tr/Td) |
| sudut pandang | 60/60/45/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 2 pcsCCFLWithout Driver |
| antarmuka sinyal | LVDS (1 ch, 6-bit), 20 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | IA |
