| Nomor Bagian | LS038Y7DX01 |
| Merek | SHARP |
| Ukuran | 3.8 |
| Aplikasi | MPH |
| Resolusi | 480×800 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | SHARP |
| model panel | LS038Y7DX01 |
| tipe panel | CG-Silicon , LCM |
| ukuran panel | 3.8 inch |
| resolusi | 480(RGB)×800 , WVGA |
| mode tampilan | Normally Black, Transflective |
| daerah aktif | 49.68×82.8 mm |
| garis besar | 54.6×93 mm |
| permukaan | |
| kecerahan | 300 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.)(Transmissive)12:1 (Typ.)(Reflective) |
| menampilkan warna | 262K (6-bit), CIE193170% |
| waktu merespon | 40/40 (Typ.)(Tr/Td) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 7S1PWLEDWithout Driver |
| antarmuka sinyal | Parallel RGB (1 ch, 6-bit) + SPI, 50 pins |
| tegangan masukan | 3.85/1.8V (Typ.)(VDC/VDDIO) |
| roh: | |
| aplikasi | MPH |
