| Nomor Bagian | AMS470GS16-1 |
| Merek | Samsung |
| Ukuran | 4.7 |
| Aplikasi | MPH |
| Resolusi | 720×1280 |
| Komposisi | Assembly |
| Kecerahan | 300 |
| CR | 3400:1 |
| Warna | 16.7M |
| Lampu latar | self |
| Antarmuka | MIPI |
| merek panel | SAMSUNG |
| model panel | AMS470GS16-1 |
| tipe panel | AM-OLED , Assembly |
| ukuran panel | 4.7 inch |
| resolusi | 720RG(BG)×1280 , WXGA |
| daerah aktif | 57.96×103.04 mm |
| garis besar | 66.36×131.8 mm |
| permukaan | Hard coating |
| kecerahan | 300 cd/m² (Typ.) |
| rasio kontras | 3400 : 1 (Min.) |
| menampilkan warna | 16.7M (8-bit), CIE1931110% |
| sudut pandang | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| antarmuka sinyal | MIPI (4 data lanes), 44 pins |
| tegangan masukan | 2.5/3.1/3.8V (VDD3/VCI/VBAT) |
| aplikasi | MPH |
