| Nomor Bagian | LR043AC212 |
| Merek | Innolux |
| Ukuran | 4.3 |
| Aplikasi | PND |
| Resolusi | 480×272 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 400:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | Parallel/Serial |
| merek panel | ChiHsin |
| model panel | LR043AC212 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 4.3 inch |
| resolusi | 480(RGB)×272 , WQVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 95.04×53.856 mm |
| garis besar | 105.5×67.2 mm |
| permukaan | Antiglare |
| kecerahan | 300 cd/m² (Typ.) |
| rasio kontras | 400:1 (Typ.) |
| menampilkan warna | 16.7M |
| waktu merespon | 15/35 (Typ.)(Tr/Td) |
| sudut pandang | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 7S1PWLEDWithout Driver |
| antarmuka sinyal | Digital RGB (8/24-bit), 60 pins |
| tegangan masukan | 3/5.0V (Typ.)(DVDD/AVDD) |
