| Nomor Bagian | LQ036T1DG01 |
| Merek | SHARP |
| Ukuran | 3.6 |
| Aplikasi | PND |
| Resolusi | 272×480 |
| Komposisi | LCM |
| Kecerahan | 410 |
| CR | 300:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | SHARP |
| model panel | LQ036T1DG01 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 3.6 inch |
| resolusi | 272(RGB)×480 , WQVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 44.472×78.48 mm |
| garis besar | 51.8×90 mm |
| permukaan | Antiglare, Hard coating (2H) |
| kecerahan | 410 cd/m² (Typ.) |
| rasio kontras | 300:1 (Typ.) |
| menampilkan warna | 262K (6-bit), CIE193150% |
| waktu merespon | 30/30 (Typ.)(Tr/Td) |
| sudut pandang | 40/60/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antarmuka sinyal | Parallel RGB + SPI, 67 pins |
| tegangan masukan | 1.8/2.5V (Typ.)(VDDIO/VCI) |
| aplikasi | PND |
