| Nomor Bagian | LQ080M1SX01 |
| Merek | Sharp |
| Ukuran | 8.0 |
| Aplikasi | Pad & Tablet |
| Resolusi | 1200×1920 |
| Komposisi | Oxide TFT-LCD , LCM |
| Kecerahan | |
| CR | 1500:1 |
| Warna | 16.7M |
| Lampu latar | 5S5P |
| Antarmuka | |
| merek panel | Sharp |
| ukuran panel | 8.0" |
| resolusi | 1200(RGB)×1920, WUXGA, 284PPI |
| area tampilan | 107.28(W)×171.648(H) mm |
| ukuran garis besar | 112.38(W)×182.75(H) ×3.19(D) mm |
| kecerahan | 500 cd/m² (Typ.) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 90% NTSC |
| frekuensi | 75Hz |
| berat | 67g (Max.) |
| model panel | LQ080M1SX01 |
| tipe panel | Oxide TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Clear, Hard coating |
| rasio kontras | 1500:1 (Typ.) (TM) |
| mode tampilan | IPS, Normally Black, Transmissive |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| jenis lampu | 5S5P WLED , 15K hours , Without Driver |
| layar sentuh | Without |
| aplikasi | Pad & Tablet |
