| Nomor Bagian | LPM035M407B |
| Merek | JDI |
| Ukuran | 3.5 |
| Aplikasi | HMD VR AR |
| Resolusi | 1440×1600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek | JDI |
| model | LPM035M407B |
| ukuran diagonal | 3.5 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1440(RGB)×1600 615PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 59.4(H)×66(V) mm |
| garis besar redup. | 62.2(H)×73.6(V) mm |
| daerah bezel | - |
| perlakuan | Hard coating |
| arah pandangan | Symmetry |
| waktu merespon | - |
| sudut pandang | - |
| Modus operasi | IPS, Normally Black, Transmissive |
| warna pendukung | 16.7M |
| sumber cahaya | WLED [5S2P] |
| berat | 17.0g (Typ.) |
| dirancang untuk | HMD VR AR |
| kecepatan bingkai | 90Hz |
| panel sentuh | Without |
| tipe antarmuka | MIPI (4 data lanes) |
| Sumber Daya listrik | 1.8/5.7/-5.7V (Typ.)(VDDI/AVDD/AVEE) |
| lingkungan | Operating Temperature: -10 ~ 55 °C ; Storage Temperature: -20 ~ 70 °C |
