LG Display LM215WF9-SLA2 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com

LM215WF9-SLA2


Merek
LG Display
Ukuran
21.5
Aplikasi
Desktop Monitor
Resolusi
1920×1080
Komposisi
LCM ,   a-Si TFT-LCD
Kecerahan
CR
1000:1
Warna
16.7M
Lampu latar
WLED
Antarmuka
LVDS
In Stock
6992
Spesifikasi

Nomor Bagian LM215WF9-SLA2
MerekLG Display
Ukuran21.5
AplikasiDesktop Monitor
Resolusi1920×1080
KomposisiLCM ,   a-Si TFT-LCD
Kecerahan
CR1000:1
Warna16.7M
Lampu latarWLED
AntarmukaLVDS
pabrikanLG Display
nama modelLM215WF9-SLA2
ukuran layar21.5 inch
tipe layarLCM ,   a-Si TFT-LCD
nomor piksel1920(RGB)×1080   (FHD)  102PPI
pengaturanRGB Vertical Stripe
area aktif (mm)476.064 × 267.786 (H×V)
garis besar (mm)489.3 × 287 × 12.8 (H×V×D)
area bezel (mm)-
perlakuanAntiglare (Haze 25%), Hard coating (3H)
pencahayaan250 cd/m² (Typ.)
rasio kontras1000 : 1 (Typ.) (TM)
sudut pandang89/89/89/89 (Typ.)(CR≥10)
tanggapan14 (Typ.)(G to G) ms
pemandangan bagus diSymmetry
mode kerjaIPS, Normally Black, Transmissive
kedalaman warna16.7M   72% NTSC
lampu latarWLED , 30K hours , No Driver
massa1.64Kgs
digunakan untukDesktop Monitor
tingkat penyegaran60Hz
layar sentuhWithout
jenis sinyalLVDS (2 ch, 8-bit) , 30 pins Connector
sumber tegangan5.0V (Typ.)
maks. peringkatStorage Temp.: -20 ~ 60 °C    Operating Temp.: 0 ~ 50 °C
Model Keluarga
LM215WF1-TLB1 LG Display 21.5 1920×1080
LM215WF2-SLC1 LG Display 21.5 1920×1080
LM215WF3-SDA1 LG Display 21.5 1920×1080
LM215WF3-SLA1 LG Display 21.5 1920×1080
LM215WF3-SLD1 LG Display 21.5 1920×1080
LM215WF3-SLK1 LG Display 21.5 1920×1080
LM215WF3-SLM1 LG Display 21.5 1920×1080
LM215WF3-SLN1 LG Display 21.5 1920×1080
LM215WF4-TLG1 LG Display 21.5 1920×1080
LM215WF5-SLA1 LG Display 21.5 1920×1080
