| Nomor Bagian | LM140LF2L05 |
| Merek | PANDA |
| Ukuran | 14.0 |
| Aplikasi | Laptop |
| Resolusi | 1920×1080 |
| Komposisi | Oxide TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | PANDA |
| model panel | LM140LF2L05 (NCP0062) |
| ukuran panel | 14.0" |
| tipe panel | Oxide TFT-LCD, LCM |
| resolusi | 1920(RGB)×1080, FHD, 157PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 309.312(W)×173.988(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 315.81(W)×197.57(H) ×3(D) mm |
| permukaan | Hard coating |
| kecerahan | 250 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| mode tampilan | PAS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| menampilkan warna | 16.7M 45% NTSC |
| jenis lampu | WLED , 15K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| aplikasi | Laptop |
| antarmuka sinyal | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B140HTN01.3 | AUO | 14.0 | 1920×1080 |
| B140RTN02.3 | AUO | 14.0 | 1600×900 |
| B140XW03 V1 | AUO | 14.0 | 1366×768 |
| BT140GW01 V.0 | Innolux | 14.0 | 1366×768 |
| HSD140PHW2-A00 | HannStar | 14.0 | 1366×768 |
| LP140WD2-TLE2 | LG Display | 14.0 | 1600×900 |
| LP140WH1-TLE2 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLS1 | LG Display | 14.0 | 1366×768 |
| LTN140AT07-L01 | Samsung | 14.0 | 1366×768 |
| N140HGE-EBA | Innolux | 14.0 | 1920×1080 |
