| Nomor Bagian | LM057QB1T073 |
| Merek | SHARP |
| Ukuran | 5.7 |
| Aplikasi | IA |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 150 |
| CR | 6:1 |
| Warna | Monochrome |
| Lampu latar | WLED |
| Antarmuka | Parallel Data |
| merek panel | SHARP |
| model panel | LM057QB1T073 |
| tipe panel | STN-LCD , LCM |
| ukuran panel | 5.7 inch |
| resolusi | 320×240 , QVGA |
| mode tampilan | STN, Blue mode (Negative), Transmissive |
| daerah aktif | 115.17×86.37 mm |
| garis besar | 166×109×7.5 mm |
| permukaan | |
| kecerahan | 150 cd/m² (Typ.) |
| rasio kontras | 6:1 (Typ.) |
| menampilkan warna | Monochrome |
| waktu merespon | 190/210 (Typ.)(Tr/Td) |
| sudut pandang | 40/40/25/40 (Typ.)(CR≥2)(L/R/U/D) |
| frekuensi | 80Hz |
| jenis lampu | 1S6PWLEDEmbedded (LED Driver) |
| antarmuka sinyal | Parallel Data (4-bit), 12 pins |
| tegangan masukan | 5.0V (Typ.) |
| aplikasi | IA |
