| Nomor Bagian | LD470DXS-SCB1 |
| Merek | LG Display |
| Ukuran | 47 |
| Aplikasi | DID |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 500 |
| CR | 1400:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | LG Display |
| model panel | LD470DXS-SCB1 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 47 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mode tampilan | S-IPS, Normally Black, Transmissive |
| daerah aktif | 1039.87×584.64 mm |
| garis besar | 1046.8×591.6×50.5 mm, Videowall Seam 6.9 mm |
| permukaan | Antiglare (Haze 10%), Hard coating (3H) |
| kecerahan | 500 cd/m² (Typ.) |
| rasio kontras | 1400:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193172% |
| waktu merespon | 12 (Typ.)(G to G) |
| sudut pandang | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antarmuka sinyal | LVDS (1 ch, 8-bit), 30 pins |
| tegangan masukan | 12.0V (Typ.) |
| aplikasi | DID |
