| Nomor Bagian | LC470WUF-SCA2 |
| Merek | LG Display |
| Ukuran | 47 |
| Aplikasi | LCTV |
| Resolusi | 1920×1080 |
| Komposisi | LCM |
| Kecerahan | 500 |
| CR | 1450:1 |
| Warna | 16.7M/1.06B |
| Lampu latar | EEFL |
| Antarmuka | LVDS |
| merek panel | LG Display |
| model panel | LC470WUF-SCA2 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 47 inch |
| resolusi | 1920(RGB)×1080 , FHD |
| mode tampilan | S-IPS, Normally Black, Transmissive |
| daerah aktif | 1039.68×584.82 mm |
| garis besar | 1096×640 mm |
| permukaan | Antiglare (Haze 10%), Hard coating (3H) |
| kecerahan | 500 cd/m² (Typ.) |
| rasio kontras | 1450:1 (Typ.) |
| menampilkan warna | 16.7M/1.06B (8-bit / 8-bit + FRC), CIE193172% |
| waktu merespon | 8/10 (Typ.)(Tr/Td) |
| sudut pandang | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekuensi | 120Hz |
| jenis lampu | 20 pcsEEFLWithout Driver |
| antarmuka sinyal | LVDS (4 ch, 8/10-bit), 92 pins |
| tegangan masukan | 12.0V (Typ.) |
| aplikasi | LCTV |
