LC470EUD-SDF1

LC470EUD-SDF1
LC470EUD-SDF1
LC470EUD-SDF1 thumb LC470EUD-SDF1 thumb
Merek
LG Display
Ukuran
47
Aplikasi
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
400
CR
1600:1
Warna
16.7M/1.06B
Lampu latar
WLED
Antarmuka
LVDS
In Stock
40
Spesifikasi

Nomor Bagian LC470EUD-SDF1
MerekLG Display
Ukuran47
AplikasiLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan400
CR1600:1
Warna16.7M/1.06B
Lampu latarWLED
AntarmukaLVDS
merek panelLG Display
model panelLC470EUD-SDF1
tipe panel a-Si TFT-LCD , LCM
ukuran panel47 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanS-IPS, Normally Black, Transmissive
daerah aktif1039.68×584.82 mm
garis besar1078.6×626 mm
permukaanAntiglare (Haze 10%), Hard coating (2H)
kecerahan400 cd/m² (Typ.)
rasio kontras1600:1 (Typ.)
menampilkan warna16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172%
waktu merespon5 (Typ.)(G to G), 6 (Typ.)(MPRT)
sudut pandang89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
frekuensi120Hz+120Hz
jenis lampuWLEDEmbedded (LED Driver)
antarmuka sinyalLVDS (4 ch, 8/10-bit), 92 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
