LG Display LC320WUD-SBA1 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com
LookLCD LookLCD


LC320WUD-SBA1

LC320WUD-SBA1
LC320WUD-SBA1
LC320WUD-SBA1 thumb LC320WUD-SBA1 thumb
Merek
LG Display
Ukuran
31.5
Aplikasi
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
500
CR
1300:1
Warna
16.7M/1.06B
Lampu latar
EEFL
Antarmuka
LVDS
In Stock
15422
Spesifikasi

Nomor Bagian LC320WUD-SBA1
MerekLG Display
Ukuran31.5
AplikasiLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan500
CR1300:1
Warna16.7M/1.06B
Lampu latarEEFL
AntarmukaLVDS
merek panelLG.Philips LCD
model panelLC320WUD-SBA1
tipe panel a-Si TFT-LCD , LCM
ukuran panel31.5 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanS-IPS, Normally Black, Transmissive
daerah aktif698.4×392.85 mm
garis besar760×450 mm
permukaanAntiglare (Haze 10%), Hard coating (3H)
kecerahan500 cd/m² (Typ.)
rasio kontras1300:1 (Typ.)
menampilkan warna16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172%
waktu merespon6 (Typ.)(G to G); 8 (Typ.)(MPRT)
sudut pandang89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
frekuensi120Hz
jenis lampuEEFLEmbedded (Inverter)
antarmuka sinyalLVDS (4 ch, 8/10-bit), 92 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
Model Keluarga
LC320W01-SL01 LG Display 31.5 1366×768
LC320W01-SLA1 LG Display 31.5 1366×768
LC320WUD-SBA1 LG Display 31.5 1920×1080
LC320WUN-SBG3 LG Display 31.5 1920×1080
LC320WUN-SCA2 LG Display 31.5 1920×1080
LC320WX6-SLA3 LG Display 31.5 1366×768
LC320WXE-SCB1 LG Display 31.5 1366×768
LC320WXE-SCC1 LG Display 31.5 1366×768
LC320WXN-SAC2 LG Display 31.5 1366×768
LC320WXN-SCA1 LG Display 31.5 1366×768
