| Nomor Bagian | LTA260AP02 |
| Merek | Samsung |
| Ukuran | 26.0 |
| Aplikasi | LCTV |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 450 |
| CR | 4000:1 |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | SAMSUNG |
| model panel | LTA260AP02 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 26.0 inch |
| resolusi | 1366×768(RGB) , WXGA |
| mode tampilan | APVA, Normally Black, Transmissive |
| daerah aktif | 575.769×323.712 mm |
| garis besar | 626×373×54 mm |
| permukaan | Antiglare (Haze 14%), Hard coating (3H) |
| kecerahan | 450 cd/m² (Typ.) |
| rasio kontras | 4000:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193172% |
| waktu merespon | 8 (Typ.)(G to G) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 4 pcsCCFLEmbedded (Inverter) |
| antarmuka sinyal | LVDS (1 ch, 8-bit), 30 pins |
| tegangan masukan | 12.0V (Typ.) |
| aplikasi | LCTV |
