| Nomor Bagian | LB070WV8-SL02 |
| Merek | LG Display |
| Ukuran | 7.0 |
| Aplikasi | Industrial Automotiv |
| Resolusi | 800×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| pabrikan | LG Display |
| nama model | LB070WV8-SL02 1 Compatible |
| ukuran layar | 7.0 inch |
| tipe layar | LCM , a-Si TFT-LCD |
| nomor piksel | 800(RGB)×480 (WVGA) 133PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 152.4 × 91.44 (H×V) |
| garis besar (mm) | 170 × 106.3 × 10.7 (H×V×D) |
| area bezel (mm) | 155.2 × 94.2 (H×V) |
| perlakuan | Antiglare |
| pencahayaan | 450 cd/m² (Typ.) |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Min.)(CR≥10) |
| tanggapan | 15/10 (Typ.)(Tr/Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 60% NTSC |
| lampu latar | WLED , 50K hours , With LED Driver |
| massa | 220g (Max.) |
| digunakan untuk | Industrial Automotive Display Gaming |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | LVDS (1 ch, 8-bit) , 30 pins Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 80 °C |
| LB070WQ4-TM01 | LG Display | 7.0 | 480×234 |
| LB070WQ4-TM06 | LG Display | 7.0 | 480×234 |
| LB070WQ7-TD02 | LG Display | 7.0 | 480×234 |
| LB070WV1-TD03 | LG Display | 7.0 | 800×480 |
| LB070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LB070WV1-TD12 | LG Display | 7.0 | 800×480 |
| LB070WV3-SD03 | LG Display | 7.0 | 800×480 |
| LB070WV6-TD06 | LG Display | 7.0 | 800×480 |
| LB070WV6-TD08 | LG Display | 7.0 | 800×480 |
| LB070WV7-TL01 | LG Display | 7.0 | 800×480 |
