| Nomor Bagian | LA070WV2-TD01 |
| Merek | LG Display |
| Ukuran | 7.0 |
| Aplikasi | Automotive Display |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | 9S2P |
| Antarmuka | Parallel |
| merek panel | LG Display |
| model panel | LA070WV2-TD01 |
| ukuran panel | 7.0" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 800(RGB)×480, WVGA, 133PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 152.4(W)×91.44(H) mm |
| bukaan bezel | 154.45(W)×93.24(H) mm |
| ukuran garis besar | 169(W)×103.45(H) mm |
| permukaan | Antiglare |
| kecerahan | 550 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) (TM) |
| sudut pandang | 70/70/50/60 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | - |
| waktu merespon | 6/9 (Typ.)(Tr/Td) |
| menampilkan warna | 262K 64% NTSC |
| jenis lampu | 9S2P WLED , Without Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | 165/175g (Typ./Max.) |
| aplikasi | Automotive Display |
| antarmuka sinyal | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| tegangan masukan | 3.3/10.0/18.5/-8.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| lingkungan | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C |
