| Nomor Bagian | KG057QV1EA-G020 |
| Merek | Kyocera |
| Ukuran | 5.7 |
| Aplikasi | Industrial |
| Resolusi | 320×240 |
| Komposisi | STN-LCD , LCM |
| Kecerahan | |
| CR | 4:1 |
| Warna | Monochrome |
| Lampu latar | CCFL |
| Antarmuka | |
| merek | Kyocera |
| ukuran diagonal | 5.7 inch |
| format piksel | 320×240 [QVGA] 70PPI |
| daerah aktif | 115.18(H)×86.38(V) mm |
| pencahayaan | - |
| arah pandangan | - |
| sudut pandang | 45/45/20/40 (Typ.)(CR≥2) |
| warna pendukung | Monochrome |
| berat | - |
| kecepatan bingkai | - |
| lingkungan | Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
| model | KG057QV1EA-G020 |
| jenis | STN-LCD , LCM |
| konfigurasi | Rectangle |
| garis besar redup. | - |
| rasio kontras | 4:1 (Typ.) (TM) |
| waktu merespon | 380/120 (Typ.)(Tr/Td) |
| Modus operasi | STN, Blue mode (Negative), Transmissive |
| sumber cahaya | CCFL |
| dirancang untuk | Industrial |
| panel sentuh | Without |
