| Nomor Bagian | HV550QUB-H13 |
| Merek | BOE |
| Ukuran | 55 |
| Aplikasi | TV Sets |
| Resolusi | 38403×2160 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 1.07B |
| Lampu latar | No |
| Antarmuka | V-by-One |
| merek panel | BOE |
| ukuran panel | 55" |
| resolusi | 3840(3)×2160, UHD, 80PPI |
| area tampilan | 1209.6(W)×680.4(H) mm |
| ukuran garis besar | 1225.2(W)×696.7(H) ×1.34(D) mm |
| kecerahan | 0 cd/m² |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| kedalaman kaca | 0.50+0.50 mm |
| menampilkan warna | 1.07B 73% NTSC |
| frekuensi | 120Hz |
| ic pengemudi | COF Built-in 6 source chips |
| berat panel | 2.60Kgs (Typ.) |
| antarmuka sinyal | V-by-One 8 lane , 60 pins Connector |
| tegangan masukan | 12.0V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | HV550QUB-H13 |
| tipe panel | a-Si TFT-LCD , CELL |
| format piksel | RGBW Vertical Stripe |
| bukaan bezel | - |
| permukaan | Antiglare (Haze 1%), Hard coating (3H) |
| rasio kontras | 1200:1 (Typ.) (TM) |
| mode tampilan | ADS, Normally Black, Transmissive |
| waktu merespon | 8 (Typ.)(G to G) |
| keterusan | 7.15% (Typ.)(with Polarizer) |
| jenis lampu | No B/L |
| layar sentuh | Without |
| aplikasi | TV Sets |
