| Nomor Bagian | HSD104IXN1-A01-0299 |
| Merek | HannStar |
| Ukuran | 10.4 |
| Aplikasi | Industrial Automotiv |
| Resolusi | 1024×768 |
| Komposisi | CELL , a-Si TFT-LC |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K/16.2M |
| Lampu latar | No |
| Antarmuka | |
| pabrikan | HannStar |
| ukuran layar | 10.4 inch |
| nomor piksel | 1024(RGB)×768 (XGA) 123PPI |
| area aktif (mm) | 211.2 × 158.4 (H×V) |
| area bezel (mm) | - |
| pencahayaan | 0 (cd/m²) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| ketebalan kaca | 0.50+0.50 mm |
| kedalaman warna | 262K/16.2M 70% NTSC |
| massa | 100±10g |
| tingkat penyegaran | 60Hz |
| nama model | HSD104IXN1-A01-0299 |
| tipe layar | CELL , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 220.9 × 168.75 × 1.3 (H×V×D) |
| perlakuan | Antiglare, Hard coating (3H) |
| rasio kontras | 900 : 1 (Typ.) (TM) |
| mode kerja | IPS Pro, Normally Black, Transmissive |
| tanggapan | 30 (Typ.)(Tr+Td) ms |
| keterusan | 4.68% (Typ.)(with Polarizer) |
| lampu latar | No B/L |
| digunakan untuk | Industrial Automotive Display |
| layar sentuh | Without |
| AA104XD12--G1 | Mitsubishi | 10.4 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| DLC1040ABG-2 | Other | 10.4 | 800×600 |
| HX104X02-100 | HYDIS | 10.4 | 1024×768 |
| LQ104V1LG61 | SHARP | 10.4 | 640×480 |
| LQ10D41 | SHARP | 10.4 | 640×480 |
| LTM10C209AF | TOSHIBA | 10.4 | 640×480 |
| NL10276AC20-03 | NLT | 10.4 | 1024×768 |
| NL6448BC33-49 | NLT | 10.4 | 640×480 |
| NL8060BC26-17 | NLT | 10.4 | 800×600 |
