| Nomor Bagian | HSD101JFW1-C11 |
| Merek | HannStar |
| Ukuran | 10.1 |
| Aplikasi | Automotive Display |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | HannStar |
| model | HSD101JFW1-C11 |
| ukuran diagonal | 10.1 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×600 [WSVGA] 117PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 222.72(H)×125.28(V) mm |
| garis besar redup. | 235(H)×143(V) ×6.3(D) mm |
| daerah bezel | 226(H)×128.5(V) mm |
| perlakuan | Hard coating (3H) |
| pencahayaan | 500 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| Modus operasi | IPS Pro, Normally Black, Transflective |
| warna pendukung | 16.2M 45% NTSC |
| sumber cahaya | WLED [6S7P] , 20K hours , W/O Driver |
| berat | 265/275g (Typ./Max.) |
| dirancang untuk | Automotive Display |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | LVDS (1 ch, 8-bit) , 60 pins FPC |
| Sumber Daya listrik | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| lingkungan | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
