| Nomor Bagian | HSD101BFW6-A00 |
| Merek | HannStar |
| Ukuran | 10.1 |
| Aplikasi | Pad & Tablet |
| Resolusi | 1024×600 |
| Komposisi | CELL, a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | |
| pabrikan | HannStar |
| nama model | HSD101BFW6-A00 |
| ukuran layar | 10.1 inch |
| tipe layar | CELL, a-Si TFT-LCD |
| nomor piksel | 1024(RGB)×600 (WSVGA) 117PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 222.72 × 125.28 (H×V) |
| garis besar (mm) | 230.4 × 134.2 × 0.8 (H×V×D) |
| pencahayaan | 0 cd/m² |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tanggapan | 10/20 (Typ.)(Tr/Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | IPS Pro, Normally Black, Transmissive |
| ketebalan kaca | 0.40+0.40 mm |
| keterusan | 5.81% (Typ.)(with Polarizer) |
| kedalaman warna | 16.7M 45% NTSC |
| lampu latar | No B/L |
| massa | - |
| digunakan untuk | Pad & Tablet |
| tingkat penyegaran | - |
| layar sentuh | Without |
| daftar ic driver | Suggest COG EK79007AD, HX8282-C, EK73215BCGA, HX8696-A |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
