| Nomor Bagian | HSD090JFW1-A02 |
| Merek | HannStar |
| Ukuran | 9.0 |
| Aplikasi | Automotive Display |
| Resolusi | 1024×600 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.2M |
| Lampu latar | 3S13P |
| Antarmuka | LVDS |
| pabrikan | HannStar |
| nama model | HSD090JFW1-A02 |
| ukuran layar | 9.0 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 1024(RGB)×600 (WSVGA) 132PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 196.608 × 114.15 (H×V) |
| garis besar (mm) | 211.1 × 126.5 × 6 (H×V×D) |
| area bezel (mm) | 200.01 × 117.55 (H×V) |
| perlakuan | Antiglare, Hard coating (3H) |
| pencahayaan | 500 cd/m² (Typ.) |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tanggapan | 17/18 (Typ.)(Tr/Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | IPS Pro, Normally Black, Transmissive |
| kedalaman warna | 16.2M 50% NTSC |
| lampu latar | 3S13P WLED , 15K hours , No Driver |
| massa | 226g (Typ.) |
| digunakan untuk | Automotive Display |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | LVDS (1 ch, 8-bit) , FPC 40 pins |
| sumber tegangan | 3.3/12.5/23/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.9G (28.4 m/s²) |
