| Nomor Bagian | HM200WD1-100 |
| Merek | BOE |
| Ukuran | 20.0 |
| Aplikasi | DMPC |
| Resolusi | 1600×900 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | BOE |
| model panel | HM200WD1-100 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 20.0 inch |
| resolusi | 1600(RGB)×900 , HD+ |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 442.8×249.075 mm |
| garis besar | 462.8×272 mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 250 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) |
| menampilkan warna | 16.7M (6-bit + Hi-FRC) |
| waktu merespon | 1.5/3.5 (Typ.)(Tr/Td) |
| sudut pandang | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 13S4PWLEDWithout Driver |
| antarmuka sinyal | LVDS (2 ch, 8-bit), 30 pins |
| tegangan masukan | 5.0V (Typ.) |
| aplikasi | DMPC |
| HM200WD1-100 | BOE | 20.0 | 1600×900 |
| LM200WD1-TLC1 | LG Display | 20.0 | 1600×900 |
| LM200WD1-TLD1 | LG Display | 20.0 | 1600×900 |
| LTM200KP01 | Samsung | 20.0 | 1600×900 |
| LTM200KT05 | Samsung | 20.0 | 1600×900 |
| LTM200KT10 | Samsung | 20.0 | 1600×900 |
| M200O1-L05 | Innolux | 20.0 | 1600×900 |
| MT200LW02 V.0 | Innolux | 20.0 | 1600×900 |
| T200XW01 V0 | AUO | 20.0 | 1366×768 |
| T200XW02 V0 | AUO | 20.0 | 1366×768 |
| LM238WQ1-SLA1 | LG Display | 23.8 | 2560×1440 |
| LM240WU8-SLA3 | LG Display | 24.0 | 1920×1200 |
| LM270WQ1-SDBV | LG Display | 27.0 | 2560×1440 |
| LM340UW2-SSA1 | LG Display | 34 | 3440×1440 |
| LTM190E4-L02 | Samsung | 19.0 | 1280×1024 |
| LTM240CT04 | Samsung | 24.0 | 1920×1200 |
| M190E5-L0G | Innolux | 19.0 | 1280×1024 |
| MT190AW01 V.7 | Innolux | 19.0 | 1440×900 |
| MT230DW01 V.0 | Innolux | 23.0 | 1920×1080 |
| P270MWN1 R0 | IVO | 27.0 | 1920×1080 |
