| Nomor Bagian | GV185FHM-N10-3M30 |
| Merek | BOE |
| Ukuran | 18.5 |
| Aplikasi | Industrial |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | BOE |
| model | GV185FHM-N10-3M30 |
| ukuran diagonal | 18.5 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1920(RGB)×1080 [FHD] 119PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 408.96(H)×230.04(V) mm |
| garis besar redup. | 430.4(H)×254.6(V) ×12.5(D) mm |
| daerah bezel | 410.96(H)×232.04(V) mm |
| perlakuan | Antiglare (Haze 25%), Hard coating (3H) |
| pencahayaan | 350 cd/m² (Typ.) |
| rasio kontras | 1200:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| Modus operasi | ADS, Normally Black, Transmissive |
| warna pendukung | 16.7M 70% NTSC |
| sumber cahaya | WLED [11S4P] , With LED Driver |
| berat | 1.80Kgs (Typ.) |
| dirancang untuk | Industrial |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Sumber Daya listrik | 5.0V (Typ.) |
| lingkungan | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
