| Nomor Bagian | G270ZAN01.3 |
| Merek | AUO |
| Ukuran | 27.0 |
| Aplikasi | Industrial Medical I |
| Resolusi | 3840×2160 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 10S8P |
| Antarmuka | eDP |
| pabrikan | AUO |
| nama model | G270ZAN01.3 |
| ukuran layar | 27.0 inch |
| tipe layar | LCM , a-Si TFT-LCD |
| nomor piksel | 3840(RGB)×2160 (UHD) 163PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 596.16 × 335.34 (H×V) |
| garis besar (mm) | 630 × 368.2 × 19.8 (H×V×D) |
| area bezel (mm) | 602.0 × 340.4 (H×V) |
| perlakuan | Antiglare, Hard coating (3H) |
| pencahayaan | 350 cd/m² (Typ.) |
| rasio kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tanggapan | 16/25 (Typ./Max.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | AHVA, Normally Black, Transmissive |
| kedalaman warna | 16.7M 99% Adobe RGB |
| lampu latar | 10S8P WLED , 30K hours , No Driver |
| massa | 3.30Kgs (Typ.) |
| digunakan untuk | Industrial Medical Imaging |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | eDP (4 Lanes) , HBR2 (5.4G/lane) , 51 pins Connector |
| sumber tegangan | 12.0V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
