| Nomor Bagian | G185XW01 V201 |
| Merek | AUO |
| Ukuran | 18.5 |
| Aplikasi | Industrial |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | AUO |
| model panel | G185XW01 V201 |
| ukuran panel | 18.5" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1366(RGB)×768, WXGA, 84PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 409.8(W)×230.4(H) mm |
| bukaan bezel | 413.4(W)×234.0(H) mm |
| ukuran garis besar | 430.4(W)×254.7(H) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 450 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| sudut pandang | 85/85/80/80 (Typ.)(CR≥10) |
| mode tampilan | TN, Normally White, Transmissive |
| tampilan terbaik di | - |
| waktu merespon | 3.5/1.5 (Typ.)(Tr/Td) |
| menampilkan warna | 16.7M 70% NTSC |
| jenis lampu | WLED , 50K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | 1.44Kgs (Max.) |
| aplikasi | Industrial |
| antarmuka sinyal | LVDS (1 ch, 8-bit) , 30 pins Connector |
| tegangan masukan | 5.0V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
