| Nomor Bagian | G156HAB02.5 |
| Merek | AUO |
| Ukuran | 15.6 |
| Aplikasi | Industrial |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, Assemb |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek | AUO |
| model | G156HAB02.5 |
| ukuran diagonal | 15.6 inch |
| jenis | a-Si TFT-LCD, Assembly |
| format piksel | 1920(RGB)×1080 [FHD] 141PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 344.16(H)×193.59(V) mm |
| garis besar redup. | - |
| daerah bezel | - |
| perlakuan | Hard coating (5H) |
| pencahayaan | - |
| rasio kontras | 800:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| Modus operasi | - |
| warna pendukung | 16.2M |
| sumber cahaya | WLED , 50K hours , With LED Driver |
| berat | - |
| dirancang untuk | Industrial |
| kecepatan bingkai | 60Hz |
| panel sentuh | On-Cell Touch |
| tipe antarmuka | eDP (2 Lanes) , eDP1.2 |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
