| Nomor Bagian | G104XGE-L05 |
| Merek | Innolux |
| Ukuran | 10.4 |
| Aplikasi | IA |
| Resolusi | 1024×768 |
| Komposisi | LCM |
| Kecerahan | 500 |
| CR | 1200:1 |
| Warna | 262K/16.2M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | CHIMEI INNOLUX |
| model panel | G104XGE-L05 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 10.4 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mode tampilan | Super MVA, Normally Black, Transmissive |
| daerah aktif | 210.4×157.8 mm |
| garis besar | 225.5×176.3×9.2 mm |
| permukaan | Glare (Haze 0%), Hard coating (3H) |
| kecerahan | 500 cd/m² (Typ.) |
| rasio kontras | 1200:1 (Typ.) |
| menampilkan warna | 262K/16.2M (6-bit / 6-bit + FRC), CIE193155% |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antarmuka sinyal | LVDS (1 ch, 6/8-bit), 30 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | IA |
