| Nomor Bagian | ET024012DMA |
| Merek | EDT |
| Ukuran | 2.4 |
| Aplikasi | Handheld & PDA |
| Resolusi | 240×320 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 820:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | 8/9/16/18-bit |
| merek | EDT |
| model | ET024012DMA |
| ukuran diagonal | 2.4 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 240(RGB)×320 [QVGA] 166PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 36.72(H)×48.96(V) mm |
| garis besar redup. | 42.72(H)×60.4(V) mm |
| daerah bezel | 37.72(H)×49.96(V) mm |
| perlakuan | - |
| pencahayaan | 350 cd/m² (Typ.) |
| rasio kontras | 820:1 (Typ.) (TM) |
| arah pandangan | - |
| waktu merespon | 35 (Typ.)(Tr+Td) |
| sudut pandang | 70/70/70/70 (Typ.)(CR≥10) |
| Modus operasi | TN, Normally White, Transmissive |
| warna pendukung | 262K 59% NTSC |
| sumber cahaya | WLED [4S1P] , 10K hours , W/O Driver |
| berat | - |
| dirancang untuk | Handheld & PDA |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | 8/9/16/18-bit 8080 parallel , 35 pins FPC |
| Sumber Daya listrik | 3.0/3.0V (Typ.)(VCI/IOVCC) |
| lingkungan | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
