| Nomor Bagian | DLC1040ABG-T-2 |
| Merek | Other |
| Ukuran | 10.4 |
| Aplikasi | CNS |
| Resolusi | 800×600 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | DLC |
| model panel | DLC1040ABG-T-2 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 10.4 inch |
| resolusi | 800(RGB)×600 , SVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 211.2×158.4 mm |
| garis besar | 236×183 mm |
| permukaan | |
| kecerahan | 350 cd/m² (Typ.) |
| rasio kontras | 400:1 (Typ.) |
| menampilkan warna | 262K (6-bit) |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| sudut pandang | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antarmuka sinyal | LVDS (1 ch, 6-bit), 20 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | CNS |
