| Nomor Bagian | CLAA069LA0HCW |
| Merek | CPT |
| Ukuran | 7.0 |
| Aplikasi | Automotive Display |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | |
| merek panel | CPT |
| ukuran panel | 7.0" |
| resolusi | 800(RGB)×480, WVGA, 134PPI |
| area tampilan | 156.6(W)×81.6(H) mm |
| sudut pandang | 75/75/60/70 (Typ.)(CR≥10) |
| tampilan terbaik di | 6 o'clock |
| menampilkan warna | 262K 70% NTSC |
| frekuensi | 60Hz |
| berat | 165g (Typ.) |
| model panel | CLAA069LA0HCW |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| mode tampilan | TN, Normally White, Transmissive |
| waktu merespon | 20 (Typ.)(Tr+Td) |
| jenis lampu | WLED |
| layar sentuh | Without |
| aplikasi | Automotive Display |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| CLAA069LA0FCW | CPT | 7.0 | 800×480 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| CLAA069LB02CW | CPT | 7.0 | 800×480 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| CLAA069LC01XW | CPT | 7.0 | 800×480 |
