| Nomor Bagian | C101EAN01.1 |
| Merek | AUO |
| Ukuran | 10.1 |
| Aplikasi | Automotive Display |
| Resolusi | 1280×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek panel | AUO |
| model panel | C101EAN01.1 |
| ukuran panel | 10.1" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1280(RGB)×720, WXGA, 145PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 223.68(W)×125.82(H) mm |
| bukaan bezel | - |
| kecerahan | - |
| rasio kontras | 1000:1 (Typ.) (TM) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| mode tampilan | AHVA, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 20/20 (Max.)(Tr/Td) |
| menampilkan warna | 16.7M |
| jenis lampu | WLED |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | - |
| aplikasi | Automotive Display |
| lingkungan | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
