| Nomor Bagian | BP101WX1-400 |
| Merek | BOE |
| Ukuran | 10.1 |
| Aplikasi | PAD |
| Resolusi | 1280×800 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek panel | BOE |
| model panel | BP101WX1-400 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 10.1 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mode tampilan | ADS, Normally Black, Transmissive |
| daerah aktif | 216.96×135.6 mm |
| garis besar | 229.46×149.15×4.5 mm |
| permukaan | Antiglare, Antireflection |
| kecerahan | 350 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) |
| menampilkan warna | 16.7M (6-bit + Hi-FRC), CIE193150% |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antarmuka sinyal | MIPI (4 data lanes), 40 pins |
| tegangan masukan | 3.7V (Typ.) |
| aplikasi | PAD |
