| Nomor Bagian | BB050HDG-TC1-6D00 |
| Merek | BOE |
| Ukuran | 5.0 |
| Aplikasi | Mobile Phone |
| Resolusi | 720×1280 |
| Komposisi | AM-OLED, OLED |
| Kecerahan | |
| CR | 17000:1 |
| Warna | 16.7M |
| Lampu latar | self |
| Antarmuka | MIPI |
| merek panel | BOE |
| model panel | BB050HDG-TC1-6D00 |
| ukuran panel | 5.0" |
| tipe panel | AM-OLED, OLED |
| resolusi | 720(RGB)×1280, WXGA, 295PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 61.92(W)×110.08(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 64.12(W)×116.72(H) mm |
| permukaan | Hard coating |
| kecerahan | 350 cd/m² (Typ.) |
| rasio kontras | 17000:1 (Typ.) (TM) |
| sudut pandang | 80/80/80/80 (Min.) |
| mode tampilan | OLED |
| tampilan terbaik di | Symmetry |
| waktu merespon | - |
| menampilkan warna | 16.7M 101% NTSC |
| jenis lampu | self , 10K hours |
| frekuensi | 60Hz |
| layar sentuh | On-Cell Touch |
| ic pengemudi | COG Built-in RM67120 |
| berat panel | TBD |
| aplikasi | Mobile Phone |
| antarmuka sinyal | MIPI (4 data lanes) |
| tegangan masukan | 2.8/1.8/6.0/4.6/-3.4V (Typ.)(VCI/VDDIO/AVDD/ELVDD/ELVSS) |
| lingkungan | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
| BB050HDG-T40 | BOE | 5.0 | 720×1280 |
| BTL507212-W746L | BOE | 5.0 | 720×1280 |
| H497TLB01 | AUO | 5.0 | 720×1280 |
| HSD050FMW2-D00 | HannStar | 5.0 | 540×960 |
| LMS500HF07 | Samsung | 5.0 | 480×272 |
| LQ050T3GG01 | SHARP | 5.0 | 400×234 |
| M050SWN1 R2 | IVO | 5.0 | 480×234 |
| P50AN3 | E Ink | 5.0 | 320×234 |
| PA050XU4 | E Ink | 5.0 | 320×234 |
| YXDK050TN02-40NM03 | SEBO | 5.0 | 800×480 |
