| Nomor Bagian | YXDK050TN02-40NM03 |
| Merek | SEBO |
| Ukuran | 5.0 |
| Aplikasi | CNS |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 900 |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | SEBO |
| model panel | YXDK050TN02-40NM03 1 Compatible model |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 5.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 108×64.8 mm |
| garis besar | 120.7×75.8 mm |
| permukaan | Antiglare |
| kecerahan | 900 cd/m² (Typ.) |
| rasio kontras | 700:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit) |
| waktu merespon | 10/10 (Typ.)(Tr/Td) |
| sudut pandang | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 6S3PWLEDWithout Driver |
| antarmuka sinyal | Parallel RGB (1 ch, 8-bit), 40 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | CNS |
