| Nomor Bagian | B173HAN01.4 |
| Merek | AUO |
| Ukuran | 17.3 |
| Aplikasi | Laptop Gaming |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | AUO |
| model panel | B173HAN01.4 (AUO149D) |
| ukuran panel | 17.3" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×1080, FHD, 127PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 381.888(W)×214.812(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 398.1(W)×250.5(H) ×4(D) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| rasio kontras | 700:1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| mode tampilan | AHVA, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| menampilkan warna | 16.2M 72% NTSC |
| jenis lampu | WLED , 15K hours , With LED Driver |
| frekuensi | 120Hz |
| layar sentuh | Without |
| gaya bentuk | Flat (PCBA Flat, T3.4~4.0mm) |
| aplikasi | Laptop Gaming |
| antarmuka sinyal | eDP (4 Lanes) , eDP1.4a , 40 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B173HAN01.0 | AUO | 17.3 | 1920×1080 |
| B173HTN01.1 | AUO | 17.3 | 1920×1080 |
| B173HW01 V4 | AUO | 17.3 | 1920×1080 |
| B173HW01 V5 | AUO | 17.3 | 1920×1080 |
| B173HW02 V1 | AUO | 17.3 | 1920×1080 |
| B173RW01 V3 | AUO | 17.3 | 1600×900 |
| HSD173PUW1-A00 | HannStar | 17.3 | 1920×1080 |
| LP173WF2-TPB1 | LG Display | 17.3 | 1920×1080 |
| LP173WF3-SLB2 | LG Display | 17.3 | 1920×1080 |
| N173FGE-L23 | Innolux | 17.3 | 1600×900 |
