| Nomor Bagian | B156XTN07.0 HW1A |
| Merek | AUO |
| Ukuran | 15.6 |
| Aplikasi | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | |
| merek | AUO |
| ukuran diagonal | 15.6 inch |
| format piksel | 1366(RGB)×768 [WXGA] 100PPI |
| daerah aktif | 344.232(H)×193.536(V) mm |
| daerah bezel | - |
| pencahayaan | 200 cd/m² (Typ.) |
| arah pandangan | 6 o'clock |
| sudut pandang | 45/45/15/35 (Typ.)(CR≥10) |
| warna pendukung | 262K 45% NTSC |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| kecepatan bingkai | 60Hz |
| model | B156XTN07.0 HW1A (AUO10EC) |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 359.5(H)×223.8(V) ×3.2(D) mm |
| perlakuan | Glare (Haze 0%) |
| rasio kontras | 500:1 (Typ.) (TM) |
| waktu merespon | 8 (Typ.)(Tr+Td) |
| Modus operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED , 15K hours , With LED Driver |
| dirancang untuk | Laptop |
| panel sentuh | Without |
