| Nomor Bagian | B140QAN01.3 |
| Merek | AUO |
| Ukuran | 14.0 |
| Aplikasi | Laptop |
| Resolusi | 2560×1440 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| pabrikan | AUO |
| ukuran layar | 14.0 inch |
| nomor piksel | 2560(RGB)×1440 (Quad-HD) 210PPI |
| area aktif (mm) | 309.35 × 174.01 (H×V) |
| pencahayaan | - |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 16.7M |
| bentuk garis besar | Slim (PCBA Flat, T≤3.2mm) |
| tingkat penyegaran | 60Hz |
| jenis sinyal | eDP (4 Lanes) Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| nama model | B140QAN01.3 |
| tipe layar | LCM , a-Si TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 320.4 × 198.6 × 2.6 (H×V×D) |
| rasio kontras | 700 : 1 (Typ.) (TM) |
| tanggapan | 25 (Typ.)(Tr+Td) ms |
| mode kerja | AHVA, Normally Black, Transmissive |
| lampu latar | WLED , 15K hours , With LED Driver |
| digunakan untuk | Laptop |
| layar sentuh | Without |
