AUO B133XTN01.6 HW1A lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com
LookLCD LookLCD


B133XTN01.6 HW1A

B133XTN01.6 HW1A
B133XTN01.6 HW1A
B133XTN01.6 HW1A
B133XTN01.6 HW1A thumb B133XTN01.6 HW1A thumb B133XTN01.6 HW1A thumb
Merek
AUO
Ukuran
13.3
Aplikasi
NBPC
Resolusi
1366×768
Komposisi
LCM
Kecerahan
220
CR
400:1
Warna
262K
Lampu latar
WLED
Antarmuka
eDP
In Stock
800
Spesifikasi

Nomor Bagian B133XTN01.6 HW1A
MerekAUO
Ukuran13.3
AplikasiNBPC
Resolusi1366×768
KomposisiLCM
Kecerahan220
CR400:1
Warna262K
Lampu latarWLED
AntarmukaeDP
merek panelAUO
model panelB133XTN01.6 HW1A
tipe panel a-Si TFT-LCD , LCM
ukuran panel13.3 inch
resolusi1366(RGB)×768 , WXGA
mode tampilanTN, Normally White, Transmissive
daerah aktif293.42×164.97 mm
garis besar314.1×188.7×3 mm
gaya bentukSlim (PCBA Flat, Depth ≤3.2mm)
permukaanAntiglare, Hard coating (3H), Reflection 4.3% (Typ.)
kecerahan220 cd/m² (Typ.)
rasio kontras400:1 (Typ.)
menampilkan warna262K (6-bit), CIE193145%
waktu merespon8 (Typ.)(Tr+Td)
sudut pandang45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampuWLEDEmbedded (LED Driver)
antarmuka sinyaleDP (1 Lane), 30 pins
tegangan masukan3.3V (Typ.)
aplikasiNBPC
Model Keluarga
B133EW01 V0 AUO 13.3 1280×800
B133XTN01.0 AUO 13.3 1366×768
B133XTN01.2 AUO 13.3 1366×768
B133XTN01.5 AUO 13.3 1366×768
B133XTN01.6 HW0A AUO 13.3 1366×768
B133XTN01.6 HW1A AUO 13.3 1366×768
B133XTN02.1 AUO 13.3 1366×768
B133XW02 V0 AUO 13.3 1366×768
LP133WH2-TLN4 LG Display 13.3 1366×768
LTN133AT25-501 Samsung 13.3 1366×768
