| Nomor Bagian | AV080WSM-NW2 |
| Merek | BOE |
| Ukuran | 8.0 |
| Aplikasi | Automotive Display |
| Resolusi | 1024×600 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | 3S10P |
| Antarmuka | LVDS |
| pabrikan | BOE |
| nama model | AV080WSM-NW2 |
| ukuran layar | 8.0 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 1024(RGB)×600 (WSVGA) 148PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 176.64 × 99.36 (H×V) |
| garis besar (mm) | 192.8 × 116.9 × 4.7 (H×V×D) |
| area bezel (mm) | 180.1 × 103.4 (H×V) |
| perlakuan | - |
| pencahayaan | 600 cd/m² (Typ.) |
| rasio kontras | 800 : 1 (Typ.) (TM) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| tanggapan | 25 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | ADS, Normally Black, Transmissive |
| kedalaman warna | 262K/16.7M 50% NTSC |
| lampu latar | 3S10P WLED , 30K hours , No Driver |
| massa | 176/180g (Typ./Max.) |
| digunakan untuk | Automotive Display |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | LVDS (1 ch, 6/8-bit) , FPC 40 pins |
| sumber tegangan | 3.3/11.5/21/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| maks. peringkat | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
